Bluetooth Nordic Ibeacon Sticker CC2640 Ibeacon Beacon Bluetooth Beacon with Long Range



LINK PRODUCT DETAILS: https://www.banggood.com/Bluetooth-Nordic-Ibeacon-Sticker-CC2640-Ibeacon-Beacon-Bluetooth-Beacon-with-Long-Range-p-1103871.html?p=BH100011313440201706
Bluetooth Nordic Ibeacon Sticker CC2640 Ibeacon Beacon Bluetooth Beacon with Long Range

—————————- MORE DETAILS BELOW —————————-

Features-
1.Can be able to customize the case with your logo and the color you prefer.
2.Pre-configure the value of parameter before the shipment.
3.Package case can be customized if required.
4.APP – SDK for IOS-Android4.3 provided.
5.We have professional team provide any consultation or advice needed.
6.SDK is available to help customers build their own APP .
Specification –
Based on cc2640.
Size- 40 x 40 x 14.5mm
Work on IOS and Android. Color- Yellow- Red- Black- White -Will be sent at random-
Application for advertisement and location.
Built in pairing password to prevent others to modify the settings
Support customize your own iBeacon configuration including UUID etc. Tx Power configurable
Advertising frequecy configurable. Support upgrade firmware through OAD -air upgrade-
Built in JTAG port for customized other application firmware as a standalone system.
Manual,SDK and APP provided.
☞☞☞ WANT TO FIND MORE INFORMATION, PLEASE CLICK HERE–
Pakage included-
1 x Bluetooth Nordic Ibeacon Sticker
Detail Pictures-

Anywhere you can use this Bluetooth Nordic Ibeacon Sticker CC2640 Ibeacon Beacon Bluetooth Beacon with Long Range

Estimote Beacons Type Bluetooth 4.0 Module NRF51822 Chipset IBeacon with Silicon Case



LINK PRODUCT DETAILS: https://www.banggood.com/Estimote-Beacons-Type-Bluetooth-4_0-Module-NRF51822-Chipset-IBeacon-with-Silicon-Case-p-1103872.html?p=BH100011313440201706
Estimote Beacons Type Bluetooth 4.0 Module NRF51822 Chipset IBeacon with Silicon Case

—————————- MORE DETAILS BELOW —————————-

Features-
1.Can be able to customize the case with your logo and the color you prefer.
2.Pre-configure the value of parameter before the shipment.
3.Package case can be customized if required.
4.APP – SDK for IOS-Android4.3 provided.
5.We have professional team provide any consultation or advice needed.
6.SDK is available to help customers build their own APP .
Specification –
Based on NRF51822 or TICC2541 -optional-.
Size- 56mm x 41mm x 18mm Color- Will be sent at random.
Work on IOS and Android.
Application for advertisement and location.
Built in pairing password to prevent others to modify the settings.
Support customize your own iBeacon configuration including UUID etc.
Tx Power configurable.
Advertising frequecy configurable.
Support upgrade firmware through OAD -air upgrade-.
Built in JTAG port for customized other application firmware as a standalone system.
Manual,SDK and APP provided.
☞☞ ☞ WANT TO FIND MORE INFORMATION, PLEASE CLICK HERE–
How to use it –
Turn power on – put a magnet on the case for 1 second and move away, power on.
Turn power off – put a magnet on the case for 3 seconds and move away, power off.
Package included-
1 x Estimote Beacons Type IBeacon NOTE- The shell of white version is plastic.
Detail Pictures-

The success of the Estimote Beacons Type Bluetooth 4.0 Module NRF51822 Chipset IBeacon with Silicon Case is in its quality

I4 Mini iBeacon Near Field Orientation Module



LINK PRODUCT DETAILS: https://www.banggood.com/I4-Mini-iBeacon-Near-Field-Orientation-Module-p-1095439.html?p=BH100011313440201706
I4 Mini iBeacon Near Field Orientation Module

—————————- MORE DETAILS BELOW —————————-

Description-
Parameter name
Parameter
Remarks
Color
White
Size
Ø36x16mm
Weight
21g
Battery included
Defence
Waterproof, dustproof and shockproof
Protocol standard
iphone iBeacon Protocol
Bluetooth 4.0 technology
Battery
CR2477
Special batteries for iBeacon
Voltage
3.0VDC
Transmitted power
0dBm
-30-4dBm adjustable
Broadcast frequency
500ms
100-900ms adjustable
Suitable system
iOS7.0–Andriod 4.3-
Upgrade
Support aerial upgrade
Security
Supports password to connect and not-connection mode
Have prevent malicious connection function
Transmission Range
60-120M-open-
Radial distance
Standby time
2-3 Years
Depending on the broadcast frequency cycle
Default Parameters-
Parameters
Name
Default Values
UUID
Device ID
FDA50693-A4E2-4FB1-AFCF-C6EB07647825
Major
0-65535-Default- 10001-
Minor
0-65535-Default- 19641-
Measured power
Default -39dBm
Transmission Power
-30 to -4dBm-Default- 0dBm-
Change Password
8 characters-can be letter or number-
Broadcasting Interval
100-900ms-Default- 500ms-
Serial ID
SerialNumber
0-65535 in random
iBeacon Name
Device name
1-14 characters, Default- MiniBeacon-
Connection Mode
Yes-Connectable mode- No-not-connection mode-
Soft Reboot
The default changed password- minew123
Battery Service
100- electric quantity
Operating instructions-
Remove the insulation film it will work.Then search -BeaconSet- in app store.
Credentials-
FCC ID number- 2UAB6-MS54V3
CE Certification number- CTL201407291812-W
apple MFi certification number- iBC-14-00582
Support equipment-
Support equipment system
Supported Device types
iOS 7.0 and above
iPhone 4S,iPhone 5, iPhone 5S,iphone 6, iPhone 6p,iPad 3, iPad mini, iPad air,etc.
Android 4.3 and above
Samsung Galaxy S III, Galaxy S IV, Galaxy Note II, Galaxy Note III and Motorola Razr, HTC One, etc.
Package included-
1 x I4 Mini iBeacon Module

I really like the idea behind this I4 Mini iBeacon Near Field Orientation Module

Upgraded Version Dialog 14580 iBeacon PRO Near Field Orientation Module



LINK PRODUCT DETAILS: https://www.banggood.com/Upgraded-Version-Dialog-14580-iBeacon-PRO-Near-Field-Orientation-Module-p-1094205.html?p=BH100011313440201706
Upgraded Version Dialog 14580 iBeacon PRO Near Field Orientation Module

—————————- MORE DETAILS BELOW —————————-

Description-
It can replace the CC2541 product, less power consumption,Smaller appearance.
Features-
Size- 40 X 40 X 19mm Weight- 23g Chip- Dialog DA14580 program Coverage- More than 80M -non-blocking- Battery- CR2477 battery -1000mAh- It can work in a long time, the battery can be used more than 2 years-battery can be changed-
Package included-
1 x Upgraded Version Dialog 14580 iBeacon PRO Near Field Orientation Module

Consumers are now afraid of the counterfeit, poor quality, expensive price, this is the Upgraded Version Dialog 14580 iBeacon PRO Near Field Orientation Module that best suits their criteria.

Waterproof IBeacon TICC2541 Ibeacon Eddystone Bluetooth Ibeacon Module with Power Button



LINK PRODUCT DETAILS: https://www.banggood.com/Waterproof-IBeacon-TICC2541-Ibeacon-Eddystone-Bluetooth-Ibeacon-Module-with-Power-Button-p-1103873.html?p=BH100011313440201706
Waterproof IBeacon TICC2541 Ibeacon Eddystone Bluetooth Ibeacon Module with Power Button

—————————- MORE DETAILS BELOW —————————-

Features-
1. Waterproof beacon with Industrial battery long life time 9-10 years.
2.CC2640 Chipset ibeacon ultra low power consumption.
3.CC2540 Chipset bluetooth beacon custom.
4.NRF51822 Type beacons bluetooth 4.0.
and other customer ibeacons ble 4.0 beacon.
Note-
NRF51822 Chipset support eddystone
TI CC2541 Chipset don-t support eddystone
☞☞☞ WANT TO FIND MORE INFORMATION, PLEAE CLICK HERE–
Configuration –
1.We will send customers the APP and SDK for configuration, or customers can download lightblue in app store and we will provide videos to help.
2.After receiving the files, please install APP in your phone.
3.Then you can configure the ibeacons according to the manual we provide.
4.Almost all the values can be configured, such as uuid,major,minor,password,tx power,transmitting frequency etc.
5.If have any questions about the ibeacon configuration, please don’t hesitate to let us know.
6.The files we will provide are – Manual,SDK,APP,APP source file.
Package included-
1 x Waterproof IBeacon TICC2541 Ibeacon
Detail Pictures-

How to use the Waterproof IBeacon TICC2541 Ibeacon Eddystone Bluetooth Ibeacon Module with Power Button is extremely simple

Wristband Bluetooth Ibeacon NRF51822 Ibeacon Module with Battery



LINK PRODUCT DETAILS: https://www.banggood.com/Wristband-Bluetooth-Ibeacon-NRF51822-Ibeacon-Module-with-Battery-p-1103874.html?p=BH100011313440201706
Wristband Bluetooth Ibeacon NRF51822 Ibeacon Module with Battery

—————————- MORE DETAILS BELOW —————————-

Features-
1- Built-in iBeacon firmware.
2- Built-in a coin battery.
3- Bluetooth low energy technology compatible.
4- Excellent link budget -up to 97dB-.
5- Enable long range applications.
6- Accurate digital RSSI.
7- CE FCC MFI Certified and compatible with CE and FCC regulation.
8- High performance and low power 8051 core MCU.
9- Temperature sensor.
10- AES security coprocessor.
Specification-
1- Run standalone as iBeacon, External host is not required.
2- Based on nRF51822. 3- 1 Year battery life
4- Run standalone as iBeacon, External host is not required.
5- Application for advertisement and location.
6- Built in pairing password to prevent others to modify the settings
7- Support customize your own iBeacon configuration including UUID etc.
8- Tx Power configurable
9- Advertising frequecy configurable.
10- Support upgrade firmware through OAD -air upgrade-
11- Built in JTAG port for customized other application firmware as a standalone system
Item
Value
Remarks
Firmware
iBeacon
Version 1.3.1
Battery model
CR2477
Coin battery, 3.0Vdc, 1 pc
Operation Frequency
2400-2483.5MHz
Programmable
Frequency Error
— 20KHz
Modulation
Q-QPSK
Standby current
100uA
Depends on duty cycle-broadcasting frequency
Broadcasting Frequency
900mS
Duty cycle
Output Power
0 dBm
Default setting, programmable
Receiving Sensitivity
-93dBm
High gain mode
Transmission distance
50 meters -100meters
BER-0.1-, Open space
Antenna
50ohm
On board- PCB Antenna
Size
Adjustable
Operation Voltage
2.0-3.6V
DC
—PLEASE CLICK HERE TO DOWNLOAD ENGLISH USER MANUAL—
Configuration –
1.We will send customers the APP and SDK for configuration, or customers can download lightblue in app store and we will provide videos to help.
2.After receiving the files, please install APP in your phone.
3.Then you can configure the ibeacons according to the manual we provide.
4.Almost all the values can be configured, such as uuid,major,minor,password,tx power,transmitting frequency etc.
5.If have any questions about the ibeacon configuration, please don’t hesitate to let us know.
6.The files we will provide are – Manual,SDK,APP,APP source file.
Package included-
1 x Wristband Bluetooth Ibeacon NRF51822 Ibeacon
Detail Pictures-

With a compact design and no worries about weight, the Wristband Bluetooth Ibeacon NRF51822 Ibeacon Module with Battery is considered as a very lovely decoration-Product has been widely used and widely used all over the world
